For enterprises engaged in custom plastic toy manufacturing, small metal ornament processing, and industrial sheet metal part marking printing, three long-standing issues plague production: difficult positioning of irregular workpieces, poor adaptation to 3D height differences, and weak reproduction of fine patterns. The M-9060W, through its combined design of "head-mounted CCD visual positioning + highly adaptable hardware configuration", accurately meets the core needs of small-batch custom scenarios, transforming complex hard material printing from a "technical challenge" to "standardized production".
- Flexible Workbench: The 940×640mm workbench size is optimized for small-size workpieces. Equipped with a powerful negative pressure adsorption system, it can firmly fix various hard materials such as plastic and metal, preventing deviations caused by material warping during printing. Stable operation is achievable without additional jigs.
- Professional Printing System: Equipped with 5 Toshiba CE4 dual-channel printheads, it is compatible with high-adhesion high-spray hard ink. After curing, the ink layer features high hardness, scrub resistance, water resistance, and wear resistance. Combined with the "white + 6 colors + varnish" full-color configuration, it can not only use white ink to create a clear base on dark materials but also reproduce delicate gradients through 6-color printing. Finally, a protective layer is formed via the varnish layer, significantly enhancing the pattern’s scratch and wear resistance – making it particularly suitable for toys that are frequently touched or sheet metal parts used outdoors.
- Intelligent Positioning Core: The 1200DPI (4K) head-mounted CCD visual positioning system acts as the "precision eye" for custom production. It supports full-platform scanning and recognition, and achieves 0.1mm-level accurate alignment through a deformation matching algorithm. Whether it is the irregular contour of a toy or the curved surface of a wavy sheet metal part, it can quickly capture the position and print in a 1:1 distortion-free manner, completely eliminating the tediousness and errors of traditional manual calibration.
- Ultra-High Compatibility: The workbench can be lifted to accommodate workpieces up to 400mm in height and easily handle 3D hard materials with a height difference within 30mm, solving the adaptation problem of printing on the surface of irregular workpieces.
- Long-Term Stable Output: The printhead has a service life of over 5 years under normal use, significantly reducing the replacement cost of core components. Combined with eco-friendly UV curing technology, the ink layer dries instantly after printing, allowing immediate entry into the next process without waiting – balancing production efficiency and environmental requirements.
In personalized toy production, its 6-color printing system can accurately reproduce the gradient colors and detailed textures of cartoon patterns, while the varnish layer resists friction and scratches during children’s play. For industrial sheet metal parts, the CCD visual system can automatically identify the workpiece’s hole positions and edges, ensuring marks are printed at designated locations – even minor warping of the workpiece does not affect precision.
- ✅ Applicable Scenarios: Small-batch custom production (e.g., personalized orders of dozens to hundreds of pieces per day), fine pattern requirements, and irregular hard material processing.
- ❌ Inapplicable Scenarios: Large-scale mass production (printing speed is relatively slow, unable to meet high-capacity needs), and printing on soft materials (e.g., fabrics, soft films).
- High-spray hard ink should be stored in an environment above 5°C to avoid low-temperature solidification, which may affect printing fluency and adhesion.
- For first-time use, it is recommended to calibrate color parameters via professional RIP software to ensure the output effect is highly consistent with the design draft.
Please contact the WeChat ID or WhatsApp number on our website to obtain high-definition printing videos and learn more!
